Product Overview
The Metal Roofing Roll Forming Machine is designed for fabricating high-precision standing seam roof panels, ideal for both onsite and in-factory production. Built for contractors, steel structure installers, and commercial roofing projects, this machine enables efficient forming of metal roofing sheets with consistent quality and customizable profiles.
Its compact frame, easy operation, and mobility make it a perfect solution for project-based contractors and international distributors looking for reliable, field-proven metal roofing panel forming equipment.
Products Description
| Model NO | YX65-300-425 |
| Control System | PLC Frequency Control System with Touch Screen |
| Raw material | Al-Mg-Mn sheet, galvanized shee,colored prepainted sheet... |
| Min.Order Quantity | 1 Set/Sets |
| Usage | Production of Roof Panel |
| Packing | standard for export |
| Port | XIAMEN,China |
| Payment Terms | L/C,T/T |
Core Advantages
Compact structure and flexible mobility
The machine features a compact design with a small footprint, making it easy to transport and relocate on-site. It is particularly suitable for construction projects, enabling quick deployment, improved operational efficiency, and reduced construction timelines.
Precision forming, compatible with multiple panel types
Precision forming, compatible with multiple panel types
Equipped with high-precision forming wheels and a scientifically designed roller system, it ensures uniform panel dimensions and clean edges. Compatible with various standard vertical seam roof panels, including standing seam, snap-on cap, and concealed fastener types.
Strong Stability, Uninterrupted Operation
The main frame is constructed with high-strength welded steel and undergoes stress-relieving heat treatment, ensuring smooth and low-noise operation. Core components-such as the motor, PLC, and electrical control system-are equipped with premium branded parts, guaranteeing long-term, high-efficiency performance.
Our production and equipment
Our free service hotline:0086 13 6969 02513
NEARLY 20 YEARS
With industry experience dating back to 2011, we possess deep expertise in...
25
certificates
Our facility maintains comprehensive industry certifications and implements globally-recognized manufacturing standards across all production processes.
16
awards
We have received numerous industry awards recognizing our innovative capabilities.
Technical Specifications
| Parameter | Details |
| Size | 5800*1700*1500mm |
| Weight | 7000KGS |
| Voltage | 380V/50HZ/3PH |
| Motor Power | 7.5KW*2 sets |
| Hydraulic Power | 2.2KW |
| Forming Steps | 13steps |
| Working Speed | 8-14m/min |
| Height of Roofing | 65mm |
| Effective Width | 400mm,425mm |
| Feeding Material Width | 575-578mm,600-603mm |
| Thickness for Aluminum Sheet | 0.8-1.2mm |
| Thickness for Steel | 0.6-1.0mm |
| Min. Width of tapered roofing | 250mm |
| Min.Length of tapered roofing | 1000mm |
| Cutting,Forming Tolerance | ±2mm |
| Material | Galvanized Steel / Aluminum |
| Control System | PLC (Delta / Siemens optional) |
| Drive Type | Chain Drive |
Key Features
Technical Advantages
High-Precision Forming Rollers
The machine is equipped with hardened, chrome-coated rollers made from GCr15 steel, ensuring long service life and consistent panel profiles. These rollers are CNC-machined to achieve tight tolerances, minimizing material deformation and maintaining uniform seam alignment throughout production.
Integrated PLC Control System
With a touch-screen interface and programmable logic controller (PLC), operators can easily configure panel lengths, batch quantities, and operation speed. Real-time error detection and automated stop functions are built in, enhancing both safety and production accuracy.
Heavy-Duty Frame Construction
The main frame is constructed from high-strength welded steel, stress-relieved through annealing to prevent deformation during long-term operation. Reinforced side plates and base structure ensure stable performance even during high-speed production.
Hydraulic Cutting Mechanism
The hydraulic shear unit ensures clean, burr-free cuts with high precision. Cutting is synchronized with roll forming to prevent distortion of panel ends, reducing scrap and improving overall product quality.
Variable Speed Drive
Equipped with a frequency inverter (VFD), the roll forming line supports adjustable speed control between 0–15 m/min, allowing operators to optimize output based on material type and production requirements.
Material Compatibility
This machine handles a wide range of roofing materials including pre-painted steel, galvanized steel, aluminum, and zinc-magnesium alloy sheets. Panel thickness compatibility ranges from 0.4 mm to 0.8 mm depending on material hardness.
Quick Panel Size Adjustment
Optional spacer systems and manual wheel adjustments allow for quick reconfiguration of panel width and rib height, supporting flexibility for multi-profile production runs.
Applications
Where Precision Meets Performance
The Metal Roofing Roll Forming Machine plays a vital role in modern construction projects where long-lasting, weather-resistant, and architecturally appealing metal roofs are essential. Engineered for adaptability, this machine is widely used across multiple sectors, each demanding precision, speed, and reliability.
In industrial zones, such as manufacturing plants, logistics
parks, and agricultural facilities, the machine supports continuous production of standing seam and concealed-fix roof panels that can endure harsh environments and large-span installations. Its ability to produce long, seamless panels on-site helps contractors eliminate transportation limitations and reduce joint leakage risks.
In the commercial building sector, the machine is favored by metal roofing contractors and project developers working on shopping malls, airports, stadiums, and civic buildings. The sleek profile options and clean seam aesthetics offered by the machine's forming process meet both structural requirements and modern architectural tastes.
For prefabricated construction, especially in remote areas or export-oriented modular housing, this machine provides a compact, mobile solution that allows fabricators to bring manufacturing directly to the job site. With easy setup and reliable performance, it enables cost-effective, high-speed panel production without relying on large-scale facilities.
