65mm standing seam metal roof machine

Model No.: YX65-300-400-425
Control System: PLC Frequency Control System with Touch Screen
Raw Material: Al-Mg-Mn Sheet, Galvanized Sheet, Pre-painted Steel Coil
Min. Order Quantity: 1 Set/Sets
Usage: Production of Standing Seam Roof Panels
Send Inquiry
Chat Now
Description



Product Overview

This 65mm standing seam metal roof machine is purpose-built for professional contractors, steel structure builders, and panel system manufacturers seeking reliable, consistent, and high-precision forming of standing seam roof panels. Designed for both in-plant and on-site production, the machine supports fast changeovers, stable operation, and seamless integration with standard electric seamers.

Its core profile is 65mm high, making it ideal for a wide range of residential, commercial, and industrial roofing applications. Whether you're fabricating aluminum, galvanized steel, or coated coils, this machine delivers clean lines, tight seams, and robust weather resistance.

Our Service Processes

Our free service hotline:0086 136 9690 2513

Pre-sales Consultancy

1

>>

Confirmation of order

2

>>

Production

3

>>

Multi-Channel Shipping

4

>>

Confirmation of recei

5

>>

After-sale Services

6

Products Description



Technical Specifications
Parameter Details
Size 5800*1700*1500mm
Weight 7000KGS
Voltage 380V/50HZ/3PH
Motor Power 7.5KW*2 sets
Hydraulic Power 2.2KW
Forming Steps 13steps
Working Speed 8-14m/min
Height of Roofing 65mm
Effective Width 400mm,425mm
Feeding Material Width 575-578mm,600-603mm
Thickness for Aluminum Sheet 0.8-1.2mm
Thickness for Steel 0.6-1.0mm
Min. Width of tapered roofing 250mm
Min.Length of tapered roofing 1000mm
Cutting,Forming Tolerance ±2mm
portable standing seam machine with electric seamer compatibility

If you've worked with 65mm standing seam profiles, you already know-this is the one that gets spec'd on the big jobs. Airports, stadiums, high-rise commercial. The ones where the roof has to be right the first time, because coming back to fix it isn't an option.

This machine is built to deliver that 65mm profile, day in and day out. Run 0.4 to 0.7mm steel through it and the panels come out with a seam that stands tall, locks tight, and holds up under heavy foot traffic and serious weather. The ribs are crisp. The edges line up flush. No waves, no flare, no surprises when you're trying to engage that first panel on a windy deck.

Touchscreen PLC runs the show. Feed, form, cut-all in sequence, all on the money. You're not babysitting buttons or counting cycles. Dial in the length, hit start, and the machine takes care of the rest. Accuracy is tight enough that you're not burning through coils chasing tolerances.





Big selling point on this one? The portable option. A 65mm profile usually means big roofs, and big roofs usually mean long panels. With the portable unit, you can park it right next to the building and pull panels as long as the job demands-45, 50, even 60 meters, if you have the coil. No freight damage, no seam leaks from field splices, no waiting on deliveries that show up whenever they feel like it.

Build is all commercial-grade. Heavy-plate frame, hard-chrome rollers, precision-ground spindles with beefy bearings that handle the load. This is a machine that runs a full shift, cools down for the night, and does it again tomorrow. Week after week. Year after year.

For contractors who take on the work that everyone else bids and walks away from, this is the machine that makes it profitable. Spec it for the 65. Run it hard. Never look back.

roof forming equipment for OEM fabricators
Rollers: The Precision Core of Standing Seam Metal Roofing Forming Machines
Rollers serve as one of the core components in standing seam metal roofing forming machines. Their machining precision directly determines the stability of the panel profile, the flatness of the formed sheets, and ultimately, the waterproof performance of the roofing system. To ensure consistent high-quality output during prolonged operation, we adhere to stringent manufacturing standards in roller design and production.
Material Selection: Built for Durability
Rollers are typically crafted from high-strength alloy steel or premium tool steel, chosen for their exceptional wear resistance, deformation resistance, and ability to withstand prolonged high-frequency operation. Before entering production, all raw materials undergo rigorous composition analysis and hardness testing to verify compliance with machining specifications.
Precision Machining: Engineering Perfection
During manufacturing, rollers undergo multi-stage processing using high-precision CNC lathes, milling machines, and grinders. Each forming curve is meticulously machined and polished to ensure a flawlessly smooth contact surface with uniform dimensions, minimizing coating damage during production. Additionally, we offer custom mold development tailored to clients' specific panel profiles, guaranteeing a perfect match between roller geometry and desired sheet metal shapes.
Surface Treatment: Enhanced Performance & Longevity
To extend service life, rollers undergo heat treatment and hard chrome plating. This dual process significantly increases surface hardness and wear resistance while providing effective corrosion protection in humid or saline environments. Post-production, each roller undergoes rigorous inspection for coaxiality, dynamic balance, and dimensional accuracy to ensure vibration-free, stable operation at high forming speeds.
Quality Assurance: Delivering Consistent Precision
Our comprehensive quality control-spanning material selection, precision machining, and final inspection-ensures that rollers maintain exceptional accuracy and consistency throughout extended production runs. This unwavering commitment to excellence provides reliable profile stability for clients' roofing systems, project after project.

Top Service Industries

standing seam panel machine for contractors



We serve roofing contractors who demand precision equipment for large-scale metal roof installations.

Our machines support steel structure companies in delivering durable and visually appealing roofing systems.

We partner with building material distributors to supply reliable standing seam solutions for their markets.

Prefabricated building manufacturers rely on our equipment for consistent, high-quality roof panel production.

Our technology meets the needs of government and commercial project contractors with strict quality standards.
